Support DDR333 [PC2700] (*note)
DDR DIMM x 3
DIMM Type : 8/16/32/64/128/256/512MB & 1GB
Max Memory : 2GB
Graphics
Integrated VGA Engine in chipset
4X AGP slot
Support ADD card
IDE
Integrated ATA100 Controller
Max Disk : 144,000,000GB [by 48 bits LBA Spec.]
LAN
Integrated Intel 10/100Mbps LAN Controller
Intel PHY
Sound
Realtek AC'97 CODEC on-board
5.1 Channel
USB
USB2.0 x 6
Slots
AGP x 1
PCI x 6
CNR x 1
Storage
& Back Panel I/O
Floppy Drive Connector x 1
IDE Channel : ATA100 x 2
PS/2 Keyboard x 1
PS/2 Mouse x 1
USB Port x 2
VGA Port x 1
COM Port x 1
Printer Port x 1
Game/MIDI Port x 1
Speaker_Out x 1
Line_In x 1
MIC_In x 1
On
Board Connector
Front Panel x 1
Front Audio x 1
CPU FAN x 1
System FAN x 1
Chassis FAN x 1
Case Open Connector x 1
CD_IN x 1
MODEM_CN x 1
Wake_on_Modem x 1
IrDA x 1
S/PDIF x 1
Dr LED x 1
COM2 x 1
USB Port x 4 (optional cable)
Easy Installation Guide x 1
EzRestore Guide x 1
Bonus Pack CD disc x 1
Norton Anti-Virus CD disc x 1
Floppy Disk cable x 1
80-wire IDE cable x 1
CPU Retention Module x 1
