AMD
Athlon XP 3200+ , Athlon and Duron Processor
200 / 266 / 333/ 400 MHz system interface speed
CHIPSET
NVIDIA
nForce2 400 Ultra + MCP
MEMORIA
3
x 184-pin DDR SDRAM DIMM
Maximum 3.0 GB
Dual Channel DDR 200/266/333/400
For Dual-channel DDR (128-bit) performance, at least 2 or more DIMM modules
must be installed in both DIMMA and DIMMB. With only one DIMM module installed,
the memory performance is limited to 64-bit.
RANURAS
DE EXPANSION
5
x PCI
1 x AGP (4X / 8X)
I/O
1
x Parallel, 2 x Serial
1 x PS/2 Mouse, 1x PS/2 Keyboard
2 x Rear USB 2.0
1 x Game Port,
1 x Speak-out, 1 x Line-in, 1 x Mic.-in
1 x Floppy
4 x Front USB 2.0
1 x Front Audio
1 x IrDA
1 x CD in Connector
1 x Chassis Intrusion Connetcor
1 x WOL Connector
AUDIO
INTEGRADO
Realtek
ALC650 6-Channel AC'97 CODEC
LAN
MCP
NVIDIA MAC + Realtek RTL8201BL PHY
IDE
4
x EIDE devices
Ultra DMA33/66/100/133 Bus Master Mode
Monitoreo
de Hardware.
CPU
/ System Fan Speed
CPU Voltage
AGP Voltage
CPU Temperature
SystemTemperature
Vcore,+3.3V,+5V,+12V, -5V, -12V
TAMAÑO
ATX
Form Factor
Dimension: 24.4cm X 30.5cm ( W x L )
