• Chipset
VIA KT333CF
• Descripción del Chipset
VIA KT333CF / 8235 chipset
Supports 266/333 MHz FSB
• Gráficos
AGP slot supporting 4X AGP
Adjustable voltage from 1.5v to 1.8v
• Tipo
ATX
• Memory Type
DDR400/333 SDRAM.
• Memoria
Three DDR 2.5V DIMM sockets support up to 3GB (DDR 333/266/200, 2GB for DDR 400)
184-pin PC3200/PC2700/PC2100/PC1600 non-ECC, unbuffered DDR SDRAM memory
• Puertos de Expansión
Five 32-bit Bus Mastering PCI slots (V2.2 compliant)
One Universal 4X AGP slot
• Puertos
5 32-bit Bus Mastering PCI
• IDE
UDMA 66/100/133
• IDE Descripción
2 independent channels for 4 IDE devices
Supports up to PIO mode 5 & Ultra DMA 66/100/133
Two PCI bus mastering ATA E-IDE ports
• Audio
On board CMI 8738 audio chip providing 4-channel audio solution
6-channel audio ready when used with a SPDIF audio connector, available for purcahse at SOYO e-Store
• IO
2 RS-232 serial ports (16550 UART compatible)
One parallel printer port (SPP/EPP/ECP mode)
One FDD port (supports 3 modes, 1.2/1.44/2.88MB FDD)
Provides IrDA with optional cable for transceiver
Provides 6 USB 2.0 ports (2* rear, 4*front)
• Descripción de conectores IO
PS/2 Mini-DIN mouse & keyboard ports
Two USB 2.0 ports
One RJ45 connector
Two D-Sub 9-pin male serial ports
One D-Sub 25-pin female printer port
Audio I/O: LINE-OUT x 1, LINE-IN x 1, MIC JACK x 1
One game port
• Descripción del BIOS
Award PCI BIOS with ACPI function
Supports multiple-boot from E-IDE / SCSI / CD-ROM / FDD / LS120 / ZIP
2 Mbyte Flash ROM
• Programas de monitoreo
On board voltage monitors
CPU fan speed monitor
CPU fan speed monitor
CPU temperature monitoring through flexible thermal sensor
CPU overheating protection
• Tamaño
Four layers, 30.5 cm x 24.5 cm (12" x 9.6")
ATX form factor
• Compatibilidad
WinXP / Win2000 / WinNT / WinME / Win98SE / Linux / FreeBSD
