Procesador

Socket 478 Intel Pentium® 4 Processor (Northwood/Prescott)

FSB

400/533/800/1000+(con overclocking) MHz

Chipset

North Bridge : Intel 848P
South Bridge : Intel ICH5
LAN Chip : 3Com 3C910-A01
AC97 Audio Codec : Realtek ALC655
I/O Chip: Winbond Smart I/O W83627HF

Memoria

3 * DDR Sockets:
DDR400/333/DDR266 NON-ECC DDR SDRAM hasta 2 GB
( DIMM1 uses 2 Banks/ DIMM2 & DIMM3 share 2 Banks )
Nota 1: Si el Bus del CPU es 400 MHz, Soporta solamente memoria DDR 266.
Nota 2: Si el Bus del CPU es 533 MHz, Soporta memoria DDR 266/333
Nota 3: Si el Bus del CPU es 800 MHz, Soporta memoria DDR 266/333/400

Puertos

1 x AGP(3.0) 8X (1.5V )
5 x PCI (PCI 2.3 )

Conectores IDE

2 ATA100/66 Channels, up to 4 ATA 66/100 IDE

I/O

1 x Floppy Connector
2 x USB 2.0/1.1 header (4 ports by optional cable)
1 x CD_IN header
1 x S/PDIF in/out header (S/PDIF in/out cable optional)
1 x CPU fan header ( 1 fan rotation detection function )
2 x System fan headers ( 2 fan rotation detection function )
2 x 5 pin system panel header (Intel spec)
1 x 3 pin Power LED header
1 x Front audio header (Intel spec)
1 x IrDA header
1 x Case Open detection header
